Description:

Whether you’re upgrading from an older machine or are looking to add another zero-turn to your trailer, the new Radius S-Series delivers an unbeatable combination of durability, operator comfort, performance, and value. Choose from 48-, 52-, or 60-inch UltraCut Series 3 side-discharge cutting decks, each equipped with our exclusive flow-control baffles for a superior cut quality. An adjustable full-suspension operator seat and isolated footrest provide superior all-day mowing comfort.

Radius S-Series models are also designed for maximum durability with reduced maintenance. With just two grease points to lubricate annually, low-maintenance Hydro-Gear integrated transmissions, and reliable Kawasaki commercial engines, Radius S-Series models are built for the long haul.

Specification:

• UPC: 193308225180
• Starter: Electric
• Steering Control: Hydraulically dampened twin levers adjustable both fore and aft. Also has 2-position height adjustment.
• Front Caster Tires: 13 x 6.5-6, smooth tread, pneumatic. Caged Roller Bearings (126-3289)
• Drive Tires: 23 x 10.5-12 Super Turf TL
• Parking Brake: Lever-actuated pawl brake.
• Tractor Frame: Unibody, welded, heavy-duty 2" X 3" rectangular tubular steel.
• Blade Spindles: No maintenance, sealed and non-greasable spindles; 7.30"-diameter cutter housing contains 17mm (.67") diameter spindle shaft and hex blade drive.
• Electrical: 12-volt battery with 15-amp alternator.
• Standard Features: Engine hour meter, cup holder, tow hitch and jack receiver
• Seat: Deluxe suspension (adjustable spring suspension) seat with high back, molded foam flip-up armrests, and integral safety switch
• Transmission Speeds: Infinitely Variable
• Engine Brand: Kawasaki
• Engine Model: FX730V
• Engine Displacement: 726 cc
• Engine Series: V-Twin
• Fuel System: Carbureted
• Transmission: Hydrostatic
• Drive: Hydro-Drive
• Engine Speed: 3,800 rpm
• Engine Spec: FX730V_S26
• Air Filter: Cyclonic Air Cleaner
• Fuel Capacity: 7-gallon (26.5-L) single fuel tank with single fill location.
• Drive Description: Dual Hydro Gear ZT3100, hydrostatic transmission with charge pumps, relief valves and independent, replaceable filters.
• Fuel Type: Gas Carbureted
• PTO Engagement: MagStop electromagnetic 125-ft-lb clutch
• Drive Wheel Release: Allows unit movement without engine running.
• Fuel Indicator: Translucent Visual
• Deck Lift: Standard; foot-controlled deck lift changes cutting height and lifts the deck to maneuver around obstacles, or place in transport position.
• Carb Compliant: No
• Safety Package: Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.
• ROPS: 2-post foldable ROPS standard with seat belt and latch.
• Width
• 72.3 in (183.6 cm)
• Height
• 69.7 in (177.0 cm)
• Length
• 80.5 in (204.5 cm)
• Curb Weight
• 973
